CARBON FIBER END EFFECTOR DATA SHEET

OUR CODE_______________________________________________________ ORIGINAL PART P/N

C15-DN606-0M_______________________________________________________ 2-39-55389S

RELEASE DATE Nov. 2001_________________________________________ RELEASE NUMBER 1.3

EQUIPMENT MANUFACTURER ____________________________________EQUIPMENT TYPE

DNS ______________________________________________________________DNS 60

APPLICATION DESCRIPTION

This is a 6" , H shaped passive end effector.

Our part is featured by a better durability vs, the original. The original is made by ceramic, and then fragile.

ATTENTION: Our EE is sligtly thicker than the original, and then must be tested by the customer before ordering. Ask us before proceeding.
